LT-CR Series Crystal Oscillator With Broadband Frequency 0.1MHz To 200MHz
0.1MHz~200MHz LT-CR Series Crystal Oscillator
Quick Detail:
· Aluminum housing
· Broadband Frquency
· -40℃~+125℃ operating temperature
· SMD package
· High precision
· Low phase noise
· CMOS Output Waveform
· CE, RoHS, REACH compliant
· 1 Year Warranty
Description:
The LT-CR-O-50M-2013 is the newest addition to ZR’s line of Crystal Oscillator (XO) with a CMOS output from 0.1 to 200 MHz. This XO requires a supply voltage of 3.3V to 5.5V. They are available in a hermetically sealed surface-mount package and measure 20.5x7.6x5.3mm. These XOs are widely used in various electronic equipment and instruments in the field of national defense.
Specifications:
Electrical / Optical Characteristics (Ta=25℃±3℃)
| Items | Specification | Conditions | |
| Part Number | LT-CR-O-50M-2013 | ||
| Frequency Range | 0.1MHz~200MHz | ||
| Operating Voltage | 3.3~5.5 | ||
| Frequency Stability vs. Temperature | ±30ppm | @-40~85℃ | |
| ±100ppm | @-55~125℃ | ||
| Output Waveform | CMOS | ||
| Output Load | 15pF | ||
| Duty Cycle(%) | 45~55 | ||
| Rise/Fall Time(ns) | 0.1MHz≤F0＜10MHz | ＜20 | 0.1Vdd→0.9Vdd |
10MHz≤F0＜40MHz | ＜10 | ||
40MHz≤F0＜100MHz | ＜6 | ||
100MHz≤F0＜200MHz | ＜3 | ||
| Current Consumption(mA) | 0.1MHz≤F0＜40MHz | ＜5 | 3.3V non-loaded |
40MHz≤F0＜60MHz | ＜15 | ||
60MHz≤F0＜100MHz | ＜25 | ||
100MHz≤F0＜200MHz | ＜40 | ||
| Dimension | 20.5x12.8x5.3mm | ||
| Note: for custom specs, please contact us directly. | |||
Outline Drawing (Unit: mm):
| PIN | Function |
| 1 | Suspended |
| 7 | GND |
| 8 | Output |
| 14 | Input |
